Rim type: Hooked (Tubeless Ready)
Depth: front 35 mm , rear 40 mm
Inside width: 23,5 mm
Weight: 344 / 364 g.
Optimized for tire sizes: 27 – 33 mm
Tire pressure: Size & Pressure Chart
Profile: ART Asymmetrical
Finish: UD carbon w. waterslide decals
Wheel Size: 700c
ERD: front 569 / rear 559
Max. rider + gear weight: 120 kg
Wheelset weight: 1248 g
Weight based on lightest configuration w/o valves and rim tape (± 25 grams)
DT Swiss 240 EXP Straight Pull
Center Lock
Front 12 x 100 / Rear 12 x 142
Freehub Body: Shimano HG / Sram XDR
Alpina Ultralite Straight Pull Aero Spokes
24 Front / 24 Rear
See Spoke Info for ERD and spoke length
9th Wave Avalon SL3 wheels come with rim tape and valves installed and are hand built by our master wheel builders in the Netherlands.
Go to our product support pages to register your product and get lifetime warranty and crash replacement on your carbon rims!
| Lightweight: | ★★★★★ |
| Aerodynamics: | ★★★★☆ |
| Comfort: | ★★★★☆ |
| Stiffness: | ★★★★☆ |
| Versatility: | ★★★★☆ |
Somewhere past the halfway point of a long climb, the gradient kicks up again and every gram you’re carrying makes itself known. The Avalon SL3 is built for that moment: an entry point to our lightest road platform, built for the rider chasing the last few grams to climb faster.
It uses the same rim as the Avalon SL3 Ninefold, built with 24 Alpina Ultralite aero spokes and DT Swiss 240 EXP hubs, still exceptionally light at 1248g. DT Swiss 240 EXP hubs are known for their reliability and can be serviced at almost any bike shop.
The rim is 35mm deep at the front and 40mm at the rear, at 23.5mm internal width, hooked and tubeless ready, rated for 27 to 33mm tires. For the best aero shape, low rolling resistance and high grip, we recommend 28 to 30mm tires. The ART asymmetric rim design evens out the spoke tension between the drive and non-drive side of the rear wheel, so the wheel holds its shape under load despite the low weight.
This is the light, agile choice for riders who climb hard and want responsive handling. It is hand built in the Netherlands with rim tape and valves installed, and once you register your wheels, the carbon rims are covered for life. Read more about why wheel weight matters most on the climbs in our journal article. If you want carbon spokes, our own Onda-R hubs with ceramic bearings and the lightest wheel in our range, take a look at the Avalon SL3 Ninefold.
